IP Speaker SW30

IP Speaker SW30/SW30P

30W Output Power – Provides loud and clear audio suitable for wide-area coverage.

Seamless System Integration – Compatible with SIP, ONVIF, and HTTP API for easy connectivity.

Event-Triggered Alerts – Alarm input allows real-time automated audio notifications.

Pre-Recorded Message Playback – Supports scheduled or emergency announcements.

Compact & Rugged Design – Weather-resistant (IP55) and ideal for both indoor and outdoor use in schools, factories, and public venues.

Request a Quote

Specifications

IP Speaker SW30/SW30P is a compact yet powerful 30W IP speaker designed for high-definition audio in public address and emergency communication systems. It supports SIP, ONVIF, and HTTP API protocols, enabling seamless integration with various security and communication platforms. Available in two versions—SW30 (adapter-powered) and SW30P (PoE-powered)—it provides flexible installation options. Its durable IP55-rated enclosure ensures reliable performance in both indoor and outdoor environments. Key features include alarm input for event-triggered alerts, pre-recorded message playback for automated announcements, and the 48K OPUS codec, which delivers crystal-clear, low-latency audio, making it ideal for schools, transport hubs, industrial sites, and commercial facilities.

SW30/SW30P Specifications
Max SIP Account	2
Function	Compatible with VoIP devices and ONVIF VMS, support two-way communication, pre-recorded messages, schedule play, GPIO in, HTTP control
Protocol	SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP
Network Interface	RJ45, 10BASE-T/100BASE-TX
Codec	OPUS 48 kHz, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711 PCMA 8 kHz
DTMF	In-band, RFC2833, SIP INFO
Audio Output	30W
Material	Metal
Color	Off White & Black
Power	DC 12V/24V or POE
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 85°C
Dimension	167mm * 142mm * 232mm
Net Weight	890g

Features
Audio Performance
- 30W Output Power – High-definition, loud audio for wide-area coverage
- 48K OPUS Codec – Crystal-clear and low-latency HD audio
- Pre-Recorded Playback – Supports scheduled or emergency announcements
- Event-Triggered Alerts – Alarm input for real-time notifications
Integration & Protocols
- Supports SIP, ONVIF, and HTTP API
- Easy integration with various security and PA systems
- Ideal for public address and emergency communication platforms
Power & Installation
- SW30 – Adapter-powered version
- SW30p – PoE-powered version
- Flexible installation for different site needs
Design & Durability
- Compact & Rugged Design – Easy to mount and operate
- IP55-Rated Enclosure – Weatherproof for indoor and outdoor use
- Ideal for schools, transport hubs, factories, and public venues
Download Brochure
PDF Manual
- IP Speaker SW30/SW30P Datasheet

IP Speaker SW30/SW30P
