UC1000 IP PBX

Specifications
UC1000 is a versatile analog gateway designed to facilitate seamless connectivity between IPPBX systems, fax machines, analog phones, and telecom operators. 6*2.5G Ethernet ports, 1 SFP port, and 1 Console port, it ensures flexible and reliable communication solutions.

With its robust capacity for concurrent voice/fax processing, UC1000 delivers exceptional performance and stability, catering to the communication needs of service providers, enterprises, call centers, and residential users alike.

Compatible with the analog gateway, the UC1000 IPPBX support a wide range of codecs including G.711A, G.711U, G.729A, G.722, G.726, iLBC, and more. Leveraging standard SIP protocol, they seamlessly integrate with leading VoIP platforms, IPPBX systems, and SIP servers such as Asterisk, Issabel, 3CX, FreeSWITCH, BroadSoft, and VOS VoIP operating platforms.
Technical Specification
- Up to 3000 extension register
- 150 concurrent calls
- Storage: 256GB SSD
- RAM: DDR4 16GB
- NTP time synchronization and client time synchronization
- Update firmware online, backup/restore configuration file
- Abundant Log Info, automatically reboot, call status display
- Open API interface, support the secondary development of applications
- Support SSH remote operation and restore the factory settings
- Support SNMP for convenient device management
- Support cloud management functionality
- Support bulk device configuration through DHCP automatic deployment of configuration files
- Support volume adjustment, gain adjustment, call transfer, call hold, call waiting, call forward, caller ID display
- Three-way calling, call transfer, dial-up matching table
- Support T.38 fax relay and T.30 fax transparent, FSK and DTMF signaling
- Support Ring cadence and frequency setting, MWI (Message Waiting Indicator)
- Support Echo cancellation, Jitter buffer
- Support add, modify & delete SIP accounts ,batch add, modify & delete SIP accounts
- Support multiple SIP registrations: anonymous, this gateway registers with the endpoint
- SIP accounts can be registered to multiple servers
- Support 4 SIP server templates, with each FXS port supporting an independent SIP account
- Support TLS and SRTP security encryption technologies
- Allow/Disallow calling specific numbers, support expandable automatic callback and speed dialing
- Network type: Static IP, Dynamic,PPPoE
- Support DDNS, DNS, DHCP, DTMF relay, NAT
- Telnet, HTTP, HTTPS, SSH, TFTP, FTP
- VPN clients: OpenVPN
- Network Toolbox
Internet
- DHCP Server
- DHCP Client List
- Assign IP Address to Host
Security
- Firewall
- Audit
- Weak keys
Software & Platform:
- Linux OS
Features
PBX
- Import/Export Extensions
- Call Transfer
- Follow-Me/Ring Group/Queue
- Quickly Auto Provision IP Phones
- Support IMS
- Flexible Inbound/Outbound Route
- Blacklist
- AutoCLIP
- Time Condition
- PIN List
- Automated Attendant (IVR)
- Phonebook
- LDAP Service
- Wakeup Service
- DISA (Direct Inward System Access)
- Conference
- Call Back
- Call Parking
- Paging and Intercom
- Speed Dial
- Call Recording
- Music On Hold
- Support Open API Protocol (based on Asterisk)
- Click2call
- Support WebRTC
- Access Control Interface based on ACL
- AI TTS
- SIP Instant Messaging
Report
- Call Detail Records (CDR)
- Billing Report
General
- Support SIP & IAX2
- Abundant HD voice codecs: OPUS, AMR-NB/WB, G.722, SILK and VP8
- HD Video Calls
- Echo Canceller
System
- Simple and Convenient Configuration via Web GUI
- User Portal
- Extension User Privileges
- System Administrators Monitor
- Event Notification
- Support Backup/Restore
- Remote Management
- Hot Standby
Network
- Network configuration
- Support Static Route
- Support Fail2ban
- Secure SIP calling (TLS encryption)
- Support Multiple VPN protocols including OpenVPN, L2TP, N2N, SSTP（Not available for EAEU）
Email
- Voicemail
- Missed Calls Notification
- Email Server
- Antispam support
- Support Mail Relay
- Fax to Email
Download Brochure
PDF Manual
- UC1000 IP PBX Datasheet
